ES-265W

Product Overview

Replaces 1000w pulse start metal halide (PSMH). 265-watt LED Area/Shoebox Light with 34000 delivered lumens,Black/White/Brown, UL/cUL,DLC,CE,RoHS,SAA Listed, 5-year limited warranty.

Features

Housing:

Powder coated Die-cast aluminum

Lens Assembly:

Anti-UV with polycarbonate lens with precision individual optics for uniform illumination

Mounting:

Slip Fitter

Trunnion Mount Bracket

Yoke Mount Bracket

New Multi-Function Bracket

Recommended Use

Parking Lot & Garage

Street & Highway

Tennis Court

Billboard Lighting

Category:

Description

LED Parking Lot & Area Light, 1000W HPS/MH Replacement

Specifications

Electrical Specifications

Model No. ES-265W
Nominal Wattage 265W
Nominal Voltage 90-305VAC, 50/60Hz
277-480VAC, 50/60Hz
Maximum Current AC 2.95A (max)
Power Factor (PF) >0.95
Driver Efficiency >95%

Photometric Specifications

Luminous Flux +Lumen tolerance +/- 5%
33,125lm
CRI Ra>78
CCT 2700-6500K
Optional Beam Angle Type IV: 75*130°

Mechanical Specifications

IP&IK Rating IP66 & IK10
Lifetime 50000 hours – L70, @25°C
Heat Radiator Anodized Aluminum
Lens PC
Fixture Dimension 637*350*75mm
25.1*13.8*3 inches
Net Weight 9.35kg
Carton Dimension 750*440*180mm
Gross Weight 10.8kg
